DB120 Conduit
Features
Ledes Type DB-120 pipe is suitable for direct burial applications without concrete wrapping, generally used for underground direct burial rather than surface installation.
As the best direct burial PVC conduit in the DB series, DB120 conduit has the best physical properties, almost close to the schedule 40 conduit series. It can provide more choices for builders and electrical distributors.
- ASTM F-512 Certified
- ASTM 1784-20 Certified
- NEMA TC 6 & 8 Compliance
- Customized service available
- For electrical contractors, builders and wholesaler
Overview
ASTM Certified. Ledes Type DB 120 conduit is certified to ASTM D1784 and ASTM F-512 and complies with NEMA TC 6 & 8 codes. Contact us for more information.
Branded Product. 100% brand new materials and has high quality such as smooth interior and outside for running the electrical wires, and compliance NEC code.
Fire Rated. UL 94V-0 fire rating means no flaming out in 5s when cutting off the fire source, which will best protect your building & facilities.
Non-Metallic Pipe. Heat-, corrosion-, fire-, sunlight-, and rust resistance are pros for DB120 pipe.
Trusted Partner. 1500+ customers in services & 15+ mass project core suppliers all over the world.
Product Description
ASTM focuses on testing standards for raw materials, which can ensure that DB120 conduits have excellent performance after production.
Compared to Schedule 40 conduit, the DB 120 conduit series has a lighter weight and lower wholesale price, which can provide builders and distributors with more choices.
Ledes' entire Rigid PVC conduits have passed the UL94 fire rating certification and are approved up to UL94 V-0/5VA, the highest fire rating in the industry.
DB120 conduits are lighter than metal conduits and have advantages such as corrosion resistance and rust resistance. They can significantly save installation costs and effectively protect cables.
Customization is supported. Products can be customized according to your project and actual needs. Please consult our business manager for details.
Size Chart & Performance
Size(in) | Part No. | Avg. OD (inch) | Thickness (inch) | Length |
1 | LE-DB120A | 1.315 | 0.060 | 10ft / 20 ft |
1-1/2 | LE-DB120B | 1.900 | 0.060 | 10ft / 20 ft |
2 | LE-DB120C | 2.375 | 0.077 | 10ft / 20 ft |
3 | LE-DB120D | 3.500 | 0.118 | 10ft / 20 ft |
3-1/2 | LE-DB120E | 4.000 | 0.136 | 10ft / 20 ft |
4 | LE-DB120F | 4.500 | 0.154 | 10ft / 20 ft |
5 | LE-DB120G | 5.563 | 0.191 | 10ft / 20 ft |
6 | LE-DB120H | 6.625 | 0.227 | 10ft / 20 ft |
Basic Materials | Min. 4000 psi (28 MPa) |
Resistance to Impact | Up to 150 ft-lbf |
Stiffness | Up to 120 lfb/in. |
Joint Tightness | Min. 25 psi (170 kPa) |
Fire Rating | UL 94V-0 |
Permanency of Printing | Yes |
Rust & Sunlight Resistant | Yes |
Color | Grey or Customization |
Material | PVC |
Customized Services | Available |
Place of Origin | Dongguan, China |
Shipping | By sea |
Samples | Available |
Length | 10ft or 20ft |
DB Conduit Family
DB60 Conduit
DB60 conduit is used for direct burial and concrete cable protection and has the advantages of light weight and low cost.
DB100 Conduit
DB100 coduit has moderate cost and physical performance, suitable for civil construction projects.
DB2 Conduit
DB2 conduit is a CSA-certified direct burial conduit that complies with the requirements of the Canadian Electrical Code (CEC).
Why Ledes
1st UL & CSA Certified in China
Ledes, a leading PVC conduit manufacturer in China, is UL & CSA-certified with FT4 rating. They also have ASTM, AS / NZS 2053, IEC, ROHS, CE, and ISO certifications. With its superior quality and compliance, Ledes has become a trusted brand for electrical professionals and homeowners.
The Contractor's Choice
With 14+ years of industry experience, we've proudly served power stations, hospitals, metro systems, and solar projects, and more.
Customization
Tailored to your project, Ledes offers compliant products that save you time and cost. Meet local electrical code requirements 100% while optimizing your project.
Competitive Price
Get cost savings and a competitive edge. Purchase directly from the factory and increase your local market competitiveness.
High Quality
Ledes reach extends beyond borders. Delivering high-quality products to over 80 countries worldwide, we're proud to offer exceptional conduit solutions to customers everywhere.
Our electrical conduit & factory certified by
Certifications
● UL & CSA & ASTM & AS/NZS & IEC & ISO Certified
● 1500+ Customers in Service
● 100+ Certifications & Patents
● 15+ Construction Project Core Supplier
● 16+ Years Factory & 500+ Workers
Projects
Ledes is proud to have participated in 15+ large-scale construction projects and become the top electrical conduit supplier for real estate developers, including the United States, Canada, Australia, Saudi Arabia, Macau and other countries, and has been well received by contractors and builders!
- CHPE Project
- The Standard of Four Corners
- A.B.Brown Power Station
- Melbourne Metro Tunnel
- Abu Dhabi UAE Al Dhafra PV2 Project
- Macau Island Hospital
What Our Customer Say
FAQ
Are you a manufacturer or trading company?
Ledes is a professional PVC electrical conduit and fittings factory, and we have two different facilities located in China. Our product is UL, CSA, ASTM, IEC, AS/NZS, ROHS, and CE certified.
Do you have customized services available?
Yes, Ledes offers fully customized services for electrical conduits and fittings. Not only the color and size, we can customize based on your construction project.
What is your MOQ?
Different size of conduit has different MOQs; if you talk about PVC conduit, it is generally 3,000 meters to 5,000 meters (9,850 ft to 16,500 ft), depending on size.
What is your lead time?
The general L/D is 15 – 30 days, but it depends on your quantity.
What is your shipping port?
We shipped goods to Guangzhou or Shenzhen port. Let us know if you have any special requests.
What is your payment term?
We accept 30% T/T pre-paid, and the rest 70% needs to be paid before shipment.
Do you offer sample services?
Yes, we support sample services; contact us to claim your sample today!
How should I contact you?
You can contact us in 3 different ways: submit the contact form, send an email, or send us WhatsApp messages.
Cooperate with Ledes
Looking for a partner in distributing and wholesaling? Ledes offers a comprehensive network to distributors & wholesalers worldwide. Get exclusive access to technical and marketing resources.
Related Products
Schedule 40 PVC Conduit
Schedule 40 PVC electrical conduit is used in daily construction projects, including direct burial or ground cable protection, and is the first choice of builders and electrical contractors.
ENT Conduit
ENT Conduit is suitable for concrete pre-buried or ceiling cable installation, UL and CSA certification ensures compliance with NEC and CEC code.
DB2 Conduit CSA Certified
DB2 rigid PVC conduit complies with CSA standards and can be used for direct burial electrical installations and is widely used in North America.
Electrical Conduit Fittings
Electrical Conduit Fittings can be used for the installation and connection of PVC conduits, which can not only better protect the cables but also save installation costs.
